Additional data
|
|
Torque (soft/hard/max.)
|
21/50/- Nm
|
|
No-load speed (1st gear / 2nd gear)
|
0 – 500 / 0 – 1.900 rpm
|
|
Weight excl. battery
|
0.99
|
|
Battery type
|
Lithium-ion
|
|
Max. impact rate
|
0
|
|
Chuck capacity, min./max.
|
1=5 / 13 mm
|
|
Torque settings
|
20+2
|
Drilling diameter
|
|
Max. drilling diameter in wood
|
35
|
|
Max. drilling diameter in steel
|
10
|
|
Max. drilling diameter in masonry
|
10
|
Screw diameter
|
|
Max. screw diameter
|
10
|
Total vibration values (Drilling in metal)
|
|
Vibration emission value ah
|
1.5
|
|
Uncertainty K
|
1.3
|
Total vibration values (Impact drilling in masonry)
|
|
Vibration emission value ah
|
1.5
|
|
Uncertainty K
|
12.2
|
Noise/vibration information
|
|
Sound pressure level
|
85=5 dB(A)
|
|
Sound power level
|
96=5 dB(A)
|
|
Uncertainty K
|
5 dB
|
Drilling in metal
|
|
Vibration emission value ah
|
1.5 m/s²
|
|
Uncertainty K
|
1.3 m/s²
|
Impact drilling in masonry
|
|
Vibration emission value ah
|
1.5 m/s²
|
|
Uncertainty K
|
12.2 m/s²
|
Show more
The A-rated noise level of the power tool is typically as follows: Sound pressure level 85=5 dB(A); Sound power level 96=5 dB(A). Uncertainty K= 5 dB.
